THE ALL-ROAD-ALL-CONDITIONS RIDE
N 39° 44′ 10″ / E 2° 46′ 19″
The Orient is Jan’s perfect pragmatist; enabling you to build a bike customized exactly to your riding style, readily adaptable to seasonal conditions and the changing challenges they throw up. With light, strong tubing and geometry designed to bring out the endurance qualities of Titanium, Audax riding is well within its comfort zone. But when you add in drop outs for mudguards, and disc brakes, the Orient’s versatility and ruggedness make it ideal for longer commutes, winter training, camping or even relaxed summer evening rides.
ALL CONDITIONS RIDE
The Orient has been designed for the sheer pleasure of riding the open road, certain in the knowledge you have a machine that can cope with whatever demands you make of it. Featuring J. Guillem-trademark stiff, light and durable tubing in more relaxed angles, it’s the basis for a be-anything-you-want-it-to-be-bike. - Competitive endurance geometry - Seamless aerospace grade 3Al/2.5V Titanium - Beautifully hand brushed finish - 1.1-2” to 1.1-2” 3D printed head tube system - Flat mount disc brake mount - 1-piece 3D printed T47 bracket & chain-stay yoke - J.Guillem 3D printed disc drop outs - Internal cable routing - Mudguard and Rack mounts - 142x12mm UDH rear and 100x12mm front axle - 2 x Water Bottle Cage Mounts - 700c x 35-38mm tire compatibility - 30,9mm Seat Post/34,9mm Front Derailleur Clamp Diameter
3D Printed IMyo-Tendon Reinforced Seat Tube Junction with Integrated Seat Clamp. For 30,9mm Seat Post
Find Dealers
All measurements in mm unless otherwise noted
| Size | 49 | 52 | 54 | 56 | 58 | 60 | 62 |
| Seat tube c-t-t | 460mm | 490mm | 510mm | 530mm | 550mm | 570mm | 590mm |
| Seat tube c-t-c | 425mm | 455mm | 475mm | 495mm | 515mm | 535mm | 555mm |
| Top tube (effective) | 520mm | 531mm | 540mm | 558mm | 574mm | 587mm | 600mm |
| Top tube (actual) | 503mm | 513mm | 522mm | 539mm | 555mm | 567mm | 583mm |
| Head angle | 71° | 72° | 72° | 72,5° | 72,5° | 73° | 73° |
| Seat angle | 74.5° | 74° | 73.5° | 73.25° | 73° | 72.5° | 72.5° |
| Head tube | 150mm | 150mm | 165mm | 180mm | 200mm | 215mm | 220mm |
| Wheelbase | 998mm | 982mm | 987mm | 998mm | 1021mm | 1019mm | 1032mm |
| Front centre | 589mm | 579mm | 583mm | 594mm | 608mm | 610mm | 623mm |
| BB drop | 75mm | 75mm | 75mm | 75mm | 75mm | 75mm | 75mm |
| Chainstay | 420mm | 420mm | 420mm | 420mm | 420mm | 420mm | 420mm |
| Standover | 737mm | 751mm | 769mm | 787mm | 806mm | 824mm | 837mm |
| Stack | 553mm | 559mm | 573mm | 589mm | 608mm | 624mm | 629mm |
| Reach | 366mm | 369mm | 369mm | 380mm | 388mm | 390mm | 402mm |
If you don't know your size, use our size calculator
N 39° 44′ 10″ / E 2° 46′ 19″
With its staggeringly beautiful scenery and ice-rink-flat, smooth road surface, The Coll d'Orient is one of the most popular rides in Mallorca. At just under 5.2km, and with an average gradient of just 5.1%, it's accessible for cyclists of all levels.
The ride begins on the Ma-2100, after leaving Alaro, at 240m above sea level and rises to an overall total of 498m. The Coll d'Orient is reached just before the village of Orient, which is secluded by and nestled amongst the rolling mountains, that are greener and far less rocky than most of the Tramuntana range. If the ride and views weren’t incentive enough, the village has a couple of cafes which cater for a busy, international cycling crowd. In our opinion, the one on the right is the one to go for as its wide range of pastries and cakes complement its excellent coffee. If you’re really hungry, the Restaurant Orient’s menu is packed with local and traditional cuisine specialties, including roast suckling pig.
